DataMax Extreme Ethernet Cat 5e, Hi Flex – 22 AWG, 2 pair, unshielded, PUR, Blue

Part Number:
5021
RoHS Compliant:
Yes
Jacket Color: Blue
Colors shown are a representation only. If you require color matching please contact us direct.
Available in other colors: Black Teal

Construction Details

Pair Count:
2
AWG:
22
Solid/Stranded:
Stranded
Stranded Copper:
19/.0058
Insulation:
High Density Polyethylene, .009"
Shield:
No
Jacket Type:
PUR
Jacket Color:
Blue
Available in other colors: Black Teal
Overall Diameter:
.235"

Ratings and Approvals

RoHS Compliant:
Yes

Physical Properties

Temp Max.:
75
Temp Min.:
-40
Voltage Rating Max.:
300

Notes

Tested To:
100 MHz
